Cylindrical Membralox ceramic elements feature the same exceptional performance, mechanical and chemical resistance and service life as the well-recognized Membralox product range.
These membrane geometries are intended to be compatible with a wide range of filter suppliers housing designs. Membralox membranes are the key components of crossflow systems used in numerous food and beverage applications, such as clarification / concentration / purification of fermentation broths,dextrose syrups, fruits juices, dairy products, etc.
These Membralox ceramic elements are asymmetric multi-channel membranes composed of a porous alumina support supporting filtering layers casted on the inner surface of the lumens.
Pall Membralox membranes are made from high purity ceramic oxides in multiple geometries.
All along the manufacturing, a stringent quality control process verifies consistency of membrane characteristics versus precise acceptation criteria to deliver reproducible membrane performances, batch after batch, years after years.
Prior to release, Membralox membranes are 100% bubble point tested to confirm filtration layer and end sealing integrity.
1with filtration layer in the lumens
The 12 μm pore size ceramic support of Membralox membranes is made of high purity alpha-alumina.
2as measured by Pall proprietary permeametry method 3other pore sizes available on request
Please refer to the Pall website for a Declaration of Compliance to specific National Legislation and/or Regional Regulatory requirements for food contact use.
This information is a guide to the simplified designation structure and possible options.
For availability of specific options, please contact Pall.
Example Part Number: EC1935/1178/100nmZ
(Refer to bold references in the tables below)
Part Number: EC < Code from TABLE 1> /1178/ < Code from TABLE 2>
